9PX2200IRT2UANZ - Eaton 9PX 2200VA Rack/Tower UPS - 2U Rack/Tower - 120 VAC, 230 VAC Input
9PX2200IRT2UANZ - Eaton 9PX 2200VA Rack/Tower UPS - 2U Rack/Tower - 120 VAC, 230 VAC Input
9PX2200IRT2UANZ - Eaton 9PX 2200VA Rack/Tower UPS - 2U Rack/Tower - 120 VAC, 230 VAC Input
9PX2200IRT2UANZ - Eaton 9PX 2200VA Rack/Tower UPS - 2U Rack/Tower - 120 VAC, 230 VAC Input-4

9PX2200IRT2UANZ - Eaton 9PX 2200VA Rack/Tower UPS - 2U Rack/Tower - 120 VAC, 230 VAC Input

Eaton SKU: 9PX2200IRT2UANZ

$5,703.60 NZD

Shipping calculated at checkout

in stock.

Please Note: Estimated delivery details below

The Eaton 9PX is a proven best-in-class online UPS featuring ABM technology which extends battery service life by up to 50%. With double-conversion topology for constant power conditioning, optional battery packs for extended runtime and ENERGY STAR qualification, the 9PX tower/rackmount UPS supports your overall goal of business continuity. It's also built for scalable deployment and features a graphical LCD interface that gives you local access to configurations and settings, history and diagnostics, energy consumption and load segment control. The 9PX UPS even offers flexibility in battery types with nine models offering lithium-ion batteries.

For a well-rounded back-up power solution, you can easily pair your 9PX online UPS with the Eaton Intelligence Platform for seamless management of your connected equipment in your physical and virtual environment. In addition, select 9PX UPS models include the Eaton Gigabit Network card - the first UPS network card in the industry to comply with both UL 2900-2-2 and IEC cybersecurity standards.

Typical applications: IT, edge networks, medical/healthcare, universities, schools, industrial automation, harsh electrical environments



Features

  • Prevent critical data loss by staying powered during a blackout with up to 2.20 kW load capacity
  • 2.20 kVA load capacity provides sufficient backup during power failures







Controls/Indicators
Status Indicators

Multilingual graphical LCD display

Environmental Conditions
Sound Emission 40 dB
Battery Information
Battery Chemistry Lead Acid
Hot Swappable Yes
Battery Characteristics Sealed
General Information
Product Type Double Conversion Online UPS
Manufacturer Part Number 9PX2200IRT2UANZ
Manufacturer Website Address http://www.eaton.com
Manufacturer Eaton Corporation
Product Name 9PX 2200VA Rack/Tower UPS
Product Series 9PX
Brand Name Eaton
Physical Characteristics
Weight (Approximate) 25.02 kg
Form Factor Rack/Tower
Rack Height 2U
Height 86.5 mm
Width 605 mm
Depth 440 mm
Product Color Black
Silver
Color Family Multicolor
Power Description
Input Voltage 120 V AC
230 V AC
Output Voltage 240 V AC
Waveform Type Sine Wave
Input Voltage Range 100 V AC - 276 V AC
176 V AC - 276 V AC
Output Frequency 60 Hz
Input Frequency 60 Hz
Load Capacity (VA) 2.20 kVA
Load Capacity (Watt) 2.20 kW
Technical Information
Application/Usage University
Healthcare
IT
Industrial Automation System
Medical
Plug/Connector Type IEC 60320 C14
Phase Single Phase
Receptacle Type IEC 60320 C19
IEC 60320 C13
Receptacle Detail 2 x IEC 60320 C19
8 x IEC 60320 C13
