BPT Intercoms NZ: Complete Range Guide for Security Professionals

Essential Security Supplies

BPT intercoms are trusted by security professionals and installers across New Zealand for their Italian engineering, robust build quality, and scalable architecture. Whether you are specifying a simple audio entry system for a residential apartment or a networked video intercom solution for a commercial complex, the BPT range offers a sub-category for every application. This guide walks through the full BPT Intercom collection available at Essential Security Supplies NZ, covering every series, its key features, and the ideal use case for each.

BPT-PLX-V BPT 5-inch Video Audio Intercom Handset - modern minimalist matte white design for residential and commercial entry

What Is the BPT Intercom System?

BPT (now part of the CAME Group) is an Italian manufacturer specialising in video door entry and access control systems. The BPT range is built on a two-wire BUS architecture, meaning a single cable pair carries both power and data between the door station and indoor monitors. This dramatically simplifies installation, reduces cabling costs, and makes the system highly scalable — from a single apartment to a multi-tenant building with dozens of handsets.

BPT intercoms are designed to integrate with electric strikes, magnetic locks, automatic gate operators, and third-party access control systems, making them a natural fit for professional security installations across New Zealand. For the latest technical standards applicable to intercom and access control systems in NZ, refer to the New Zealand Security Association (NZSA) technical guidelines.

BPT Intercom Sub-Categories at Essential Security Supplies NZ

The BPT range is organised into distinct sub-categories, each targeting a specific application, aesthetic, or technology tier. Below is a breakdown of every series available.

AGT Series — Audio & Video Handsets

AGT A BPT Audio Intercom Handset - soft-touch button wall-mounted handset for residential BUS intercom systems NZ

The AGT Series is BPT's entry-level to mid-range handset line, available in both audio-only and video configurations. Both models feature a clean white finish, soft-touch buttons, and automatic door-opener functionality — making them a reliable workhorse for residential and light commercial installations.

The AGT A (audio) is a compact, wall-mounted handset with a programmable auxiliary button, latch function for gate control, and ringtone adjustment with LED exclusion indicator. It operates on 15–20 V DC via BUS and carries an IP54 rating, making it suitable for installations where the handset may be exposed to light dust or moisture ingress.

The AGT V (video) adds a 5" colour LCD display with OSD image adjustment, PAL/NTSC video standard support, and AUX2 for porter call functions. It supports up to 8 intercom calls and melody programming per call type.

View our product — BPT AGT Handsets Collection

AGT V BPT Video Intercom Handset - 5-inch colour LCD display with OSD for residential video entry systems NZ

PERLA Series — Audio & Video Handsets

PERLA Audio BI BPT Audio Intercom Handset - slim wall-mounted audio handset with ringtone control for apartment entry NZ

The PERLA Series offers a slimmer, more refined aesthetic compared to the AGT line, with a profile of just 31 mm depth. Available in audio (PERLA Audio BI) and video (PERLA Video BI) variants, the PERLA range is well suited to modern residential apartments and boutique commercial premises where aesthetics matter as much as function.

The PERLA Audio BI (model PEC BI) measures 110 × 170 × 31 mm and supports 2 intercom calls, auxiliary/porter call keys, and programmable ringtone melodies. It operates at IP30 and draws only 80 mA from the BUS in active use.

The PERLA Video BI (model PEV BI) adds a 3.5" TFT LCD display, self-inserting video from entry panels, up to 8 intercom calls, a "Panic" button for emergency porter calls, Master/Slave function, and video bouncing among receivers during simultaneous calls. It supports PAL/NTSC video and draws 200 mA from the BUS.

View our product — BPT PERLA Series Collection

PERLA Video BI BPT Video Intercom Handset - 3.5-inch TFT LCD display with Master-Slave function for apartment video entry NZ

PLX Series — Premium Handsfree Audio & Video Handsets

BPT-PLX-A BPT Audio Intercom Handset - ultra-slim 21mm matte white handsfree audio handset for premium residential entry NZ

The PLX Series represents BPT's premium handset tier, combining a modern minimalist design with a matte white finish and an ultra-slim profile. There are no visible holes on the front panel — the speaker and microphone are fully concealed — giving the PLX a distinctly architectural appearance that suits high-end residential and commercial fitouts.

The BPT-PLX-A (audio) is just 21 mm thick and supports handsfree audio, concealed LED signals, AUX2 for auxiliary and porter call functions, and automatic door-opener. It is compatible with 503 box (horizontal or vertical) and Ø 60 mm round box installations.

The BPT-PLX-V (video) adds a 5" colour display with 480 × 272 pixel resolution and OSD for colour, brightness, and contrast adjustment. At 24 mm thick, it retains the PLX's slim profile while delivering full video entry functionality including self-inserting video, Master/Slave function, and video relaying between extensions during simultaneous calls.

The BPT-PLX-V-WIFI extends the PLX-V with on-board WiFi connectivity, enabling remote call management and integration with mobile devices — ideal for installations where the resident requires remote access capability without a full IP monitor.

View our product — BPT PLX Series Collection

BPT-PLX-V BPT 5-inch Video Audio Intercom Handset - 480x272 OSD display with concealed speaker for premium entry systems NZ

XTS Series — 7" Touchscreen IP Monitor

XTS 7-inch White WIFI Monitor BPT Video Intercom - full touchscreen IP monitor with PoE and SIP protocol for smart security NZ

The XTS Series is BPT's flagship indoor monitor, designed for installations that demand the highest level of functionality and connectivity. The XTS 7" White WIFI Monitor features a 7" TFT full-touchscreen display with Optical Bonding anti-glare technology, making it highly readable in brightly lit environments such as lobbies, reception areas, and open-plan offices.

Key capabilities include RJ45 Ethernet and on-board WiFi (IEEE 802.11b/g/n), local or PoE (IEEE 802.3af) power supply, SIP protocol support with H.264 video and G.711 audio codecs, live IP camera feeds, video answering service (stores up to 100 × 10-second messages), and support for up to 19 mobile devices for remote call management. The customisable UI Creator software allows installers to tailor the interface to the end user's workflow.

The XTS is the recommended monitor for commercial, multi-tenant residential, and smart building applications where remote access, IP camera integration, and advanced call management are required.

View our product — BPT XTS Touchscreen Monitor Collection

XTS 7-inch White WIFI Monitor BPT Video Intercom - anti-glare touchscreen with IP camera feeds and SIP for commercial buildings NZ

FUTURA Series — Video Intercom Monitor

FUTURA SERIES BPT Video Intercom Monitor - 7-inch graphical interface monitor with Master-Slave and picture capture for residential NZ

The FUTURA Series sits between the standard handset range and the XTS IP monitor, offering a 7" display with a graphical interface and soft-touch navigation keys. Available in black and white, and across three models (X1 through to IP), the FUTURA is suited to residential and small commercial installations that require a larger display and richer feature set than a standard handset, without the full IP connectivity of the XTS.

Features include self-inserting video with cyclic selection, Master/Slave and video bouncing among receivers during simultaneous calls, picture capture for storing visitor images, a phonebook and AUX list user interface, and a "Panic" button. The IP model adds live IP camera feeds, audio/video message recording, and text messaging to and from the porter.

View our product — BPT Intercoms Collection

BPT Intercom Kits — Complete Entry Solutions

LC-PEC-KIT BPT LITHOS PEC Audio Intercom Kit - complete audio entry kit with brushed stainless steel door station for NZ installations

For installers and integrators who want a pre-matched, ready-to-install solution, BPT Intercom Kits bundle a door station, indoor handset, push button, and power supply into a single SKU. This eliminates component compatibility guesswork and simplifies procurement for standard residential installations.

Available kits include audio and video configurations across the LITHOS door station platform, paired with PERLA, AGT, and XTS monitors:

  • LC-PEC-KIT — LITHOS door station + PERLA Audio BI handset + push button + power supply. IP54 door station, brushed stainless steel finish, supports cable runs up to 50 m.
  • LC-AGTA-KIT — LITHOS + AGT A audio handset kit.
  • LVC-AGTV-KIT — LITHOS + AGT V video handset kit.
  • LVC-PEV-KIT — LITHOS + PERLA Video BI handset kit.
  • LVC-XTS-KIT — LITHOS + XTS 7" WIFI Monitor kit.
  • MTMVR-XTS-KIT / MTMVR-XTS-KIT-L — MTM Vandal Resistant door station + XTS 7" WIFI Monitor kit (standard and large configurations).

View our product — BPT Intercom Kits Collection

MTM Series — Modular Entry Panels

MTM SERIES BPT Fully Modular Entry Panel - configurable multi-button door station for multi-tenant and commercial intercom systems NZ

The MTM (Modular) Series provides a highly configurable door station platform for multi-tenant and commercial applications. MTM panels can be configured with multiple push buttons, name directories, and keypad modules to suit buildings with many apartments or offices.

MTM VR SERIES BPT Fully Modular Vandal Resistant Entry Panel - tamper-resistant door station for high-traffic commercial entry NZ

The MTM Vandal Resistant variant is engineered for high-traffic or exposed installations where durability and tamper resistance are priorities. Its robust construction makes it the preferred choice for apartment buildings, commercial lobbies, and any entry point subject to heavy use or potential interference.

View our product — BPT MTM Modular Entry Panels Collection

Digitha Series — Advanced Digital Entry

BPT-XVP-S BPT Wall Mounted Full Touch Screen Video Door Station - IP intercom door station for advanced digital entry systems NZ

The Digitha Series is BPT's digital video door entry platform, designed for modern multi-dwelling units requiring a fully digital, high-definition entry system. The Digitha range supports advanced call management, digital audio/video transmission, and integration with building management systems.

View our product — BPT Digitha Video Intercom Collection

Thangram Series — Compact Modern Door Panels

THANGRAM SERIES BPT Entry Panel - compact geometric door entry panel for single-family homes and modern commercial premises NZ

The Thangram Series offers a compact, contemporary door entry panel designed for single-family homes and small commercial premises. Its slim, geometric form factor suits modern architectural styles, and it integrates seamlessly with BPT's indoor monitor range.

View our product — BPT Thangram Door Entry Panel Collection

Product Specifications

Specification Detail
System Architecture Two-wire BUS (power + data on single cable pair)
Power Supply (BUS) 15–20 V DC (handsets); 14–18 V DC local or PoE IEEE 802.3af (XTS)
Display Options None (audio only) / 3.5" TFT LCD / 5" colour LCD / 7" TFT full-touchscreen
Video Standard PAL/NTSC (analogue models); H.264 (XTS IP model)
Audio Handsfree full-duplex (PLX, XTS); speaker audio (PERLA, AGT)
WiFi (selected models) IEEE 802.11b/g/n, 2.412–2.472 MHz (PLX-V-WIFI, XTS)
SIP Protocol Standard SIP, H.264 video, G.711 audio (XTS only)
IP Rating (door stations) IP54 (LITHOS, AGT A); IP30 (indoor monitors)
Operating Temperature -5°C to +40°C (indoor monitors); -25°C to +50°C (LITHOS kit door station)
Finish Options Matte white (PLX, PERLA, AGT, XTS, FUTURA); Brushed stainless steel (LITHOS door station)
Mobile Device Support Up to 19 mobile devices (XTS)
Intercom Calls 2 (PERLA Audio); up to 8 (PERLA Video, AGT V); unlimited (XTS)
Master/Slave Function Yes (PERLA Video, AGT V, PLX-V, FUTURA, XTS)
Picture Capture Yes (FUTURA, XTS)
Video Answering Service Up to 100 × 10-second messages (XTS)
Compatibility Electric strikes, magnetic locks, gate operators, IP cameras (XTS)

View our product — Full BPT Intercoms Collection for complete model-specific data.

Choosing the Right BPT Intercom for Your Application

Selecting the correct BPT sub-category comes down to three factors: the number of apartments or entry points, the required display type, and the level of remote connectivity needed. For straightforward single-family residential installations, the PERLA or AGT handsets paired with a LITHOS kit provide a clean, cost-effective solution. For premium residential fitouts where aesthetics are paramount, the PLX Series delivers an architectural finish with no visible speaker or microphone apertures. For multi-tenant buildings or commercial premises requiring IP camera integration, remote mobile access, and advanced call management, the XTS 7" WIFI Monitor is the recommended indoor unit. Where a modular, vandal-resistant door station is required for a high-traffic entry point, the MTM Series provides the configurability and durability to match.

All BPT systems are supported by Essential Security Supplies NZ with full technical documentation, spec sheets, and installation guides available on each product page.

View our product — Shop the full BPT Intercoms range at Essential Security Supplies NZ.
