FERN360 Emergency Call Point Range - SIP Towers, Pillars, Bollards and Wall-Mount Stations in Stainless Steel for Commercial and Infrastructure Sites NZ

FERN360 Emergency Call Points and SIP Bollards: Towers, Pillars and Pedestals for NZ

Essential Security Supplies

FERN360 emergency call points and SIP stations provide a robust, weatherproof solution for public safety communication across New Zealand commercial, industrial, and infrastructure sites. Available in tower, pillar, pedestal, pole-mount, bollard, and wall-mount configurations, the FERN360 range is manufactured from 304 grade stainless steel or Duragal SHS with polyester powder coat finishes, and is designed to house SIP intercoms, access control readers, keypads, and emergency communication equipment in a single vandal-resistant enclosure.

FPECSP-2020 FERN360 Emergency Call Point Tower and SIP Station - Stainless steel pedestal bollard for commercial and infrastructure sites NZ ---

Emergency Call Point Applications in New Zealand

Emergency call points serve a critical safety function in environments where members of the public or staff may need to summon assistance quickly. Common NZ applications include car parks, university and hospital campuses, transport hubs, industrial facilities, retail precincts, and public open spaces. A well-specified emergency call point enclosure protects the intercom and associated electronics from vandalism, weather, and tampering, while providing clear visual identification through backlit signage and strobe lighting. FERN360 emergency call point enclosures are designed to accept SIP-based intercom stations, allowing integration with IP phone systems, security control rooms, and cloud-based communication platforms.

FPECSP-2020 FERN360 Emergency Call Point Tower SIP Station - Installed onsite at commercial facility NZ ---

FERN360 Emergency Call Point Tower and SIP Station Range

FERN360 offers five tower and pedestal configurations to suit different site requirements, mounting conditions, and aesthetic preferences. All models are supplied with a customisable stainless steel mounting panel as standard, allowing installers to configure the internal gear tray to suit the specific intercom, reader, or keypad being installed.

FPECS-1515 - Emergency Call Point Tower (150mm x 150mm)

The FPECS-1515 is a 2506mm high tower constructed from Duragal SHS with zinc powder coat primer and top coat. It features 12-24V AC/DC strobe lighting, LED illumination above the intercom or keypad position, and a customisable stainless steel mounting panel. The larger 150mm x 150mm section provides a substantial visual presence suitable for open car parks and public spaces. View our product.

FPECS-1515 FERN360 Emergency Call Point Tower SIP Station - 150x150mm Duragal tower with strobe lighting for car parks and public spaces NZ

FPECS-R1010 - Emergency Call Point Tower (100mm x 100mm)

The FPECS-R1010 is a 2480mm high tower in 100mm x 100mm Duragal SHS with zinc powder coat finish. It includes 12-24V AC/DC strobe lighting and is designed to accept FERN360 FPAC-ERH, FPAC-ERS, and FPAC-ERSL rain hoods for additional weather protection of the intercom or reader. Supplied with a customisable mounting panel. View our product.

FPECS-R1010 FERN360 Emergency Call Point Tower SIP Station - 100x100mm Duragal tower with rain hood compatibility NZ

FPECSP-2020 - Emergency Call Point Tower and SIP Station (200mm x 200mm)

The FPECSP-2020 is a 1801mm high stainless steel tower in a 200mm x 200mm section, manufactured from 304 grade stainless steel with polyester powder coat finish. It features an externally fixed call point, backlit LED "Help Phone" graphics on three sides using flush-mounted 6mm opal polycarbonate lenses, and a customisable stainless steel mounting panel. The compact 1801mm height suits installations where a lower-profile tower is preferred. View our product.

FPECSP-2020 FERN360 Emergency Call Point Tower SIP Station - Backlit LED Help Phone signage on 304 stainless steel tower NZ

FPECS-PM22 - Emergency Call Point SIP Station, Pole Mount

The FPECS-PM22 is a pole-mount emergency call point station manufactured from 304 grade stainless steel with polyester powder coat finish. It is supplied with a customisable stainless steel mounting panel and supports optional 12-24V AC/DC strobe lighting. The pole-mount configuration suits sites where an existing pole or column is available, reducing installation cost and footprint. View our product.

FPECS-PM22 FERN360 Emergency Call Point SIP Station Pole Mount - 304 stainless steel pole-mount enclosure with optional strobe NZ ---

FERN360 Emergency Call Point Pillar and Pedestal Enclosures

For sites requiring a more substantial enclosure with internal equipment housing, FERN360 offers three pillar and pedestal models. All are manufactured from 304 grade stainless steel with polyester powder coat finish and feature a hinge-down front panel that is recess-mounted, leaving no pry bar gaps for vandals. Standard inclusions are concealed hinges and dual gas struts. Options across the range include anti-graffiti finish, customised internal gear trays, master key locking, vinyl graphics, and 30mm diameter illuminated stainless push buttons fitted with Braille pins.

FPECP-QR - Emergency Call Point Pillar and SIP Station

The FPECP-QR is a pillar-style pedestal enclosure in 304 grade stainless steel, suitable for housing SIP intercom stations, access control readers, and associated equipment. The hinge-down front panel provides easy access for installation and maintenance while eliminating vandal attack points. View our product.

FPECP-QR FERN360 Emergency Call Point Pillar SIP Station - Stainless steel pedestal enclosure installed onsite NZ

FPECP-BCC - Emergency Call Point Pillar and SIP Station

The FPECP-BCC shares the same 304 grade stainless steel construction and hinge-down front panel design as the FPECP-QR, with a different enclosure profile suited to specific mounting and equipment configurations. Available with the full range of options including anti-graffiti finish, Braille push buttons, and master key locking. View our product.

FPECP-BCC FERN360 Emergency Call Point Pillar SIP Station - 304 stainless steel pedestal enclosure with hinge-down front panel NZ ---

FERN360 Emergency Call Point Bollard and Wall Mount

FPECP-DB1400 - Emergency Call Point Bollard and SIP Station

The FPECP-DB1400 is a bollard-format emergency call point featuring backlit opal polycarbonate emergency signage. The bollard format provides a low-profile, high-visibility solution for pedestrian areas, car parks, and building entries where a tower or pillar format is not appropriate. View our product.

FPECP-DB1400 FERN360 Emergency Call Point Bollard SIP Station - Backlit opal polycarbonate signage bollard for pedestrian areas NZ

FPECP-WM - Wall Mount Emergency Call Point and SIP Station

The FPECP-WM is a wall-mount enclosure for sites where a freestanding tower or bollard is not feasible. Manufactured from 304 grade stainless steel with polyester powder coat finish, it features the same hinge-down front panel, concealed hinges, and dual gas struts as the pillar range. Options include anti-graffiti finish, customised gear trays, master key locking, vinyl graphics, and Braille push buttons. View our product.

FPECP-WM FERN360 Wall Mount Emergency Call Point SIP Station - 304 stainless steel wall-mount enclosure with hinge-down panel NZ ---

Product Specifications

Model Type Height Section / Format Material Strobe Lighting Backlit Signage
FPECS-1515 Tower 2506mm 150mm x 150mm SHS Duragal, zinc powder coat 12-24V AC/DC LED above intercom
FPECS-R1010 Tower 2480mm 100mm x 100mm SHS Duragal, zinc powder coat 12-24V AC/DC -
FPECSP-2020 Tower 1801mm 200mm x 200mm SHS 304 stainless steel, powder coat - Backlit LED, 3 sides, opal polycarbonate
FPECS-PM22 Pole Mount - Pole mount 304 stainless steel, powder coat 12-24V AC/DC (optional) -
FPECP-QR Pillar / Pedestal - Hinge-down front panel 304 stainless steel, powder coat - -
FPECP-BCC Pillar / Pedestal - Hinge-down front panel 304 stainless steel, powder coat - -
FPECP-DB1400 Bollard - Bollard Stainless steel - Backlit opal polycarbonate
FPECP-WM Wall Mount - Hinge-down front panel 304 stainless steel, powder coat - -

For full dimensional drawings and configuration options, view our complete FERN360 Emergency Call Point range.

---

Selecting the Right Emergency Call Point Format for Your Site

The choice of enclosure format depends on the site environment, available mounting points, equipment to be housed, and aesthetic requirements. Tower formats (FPECS-1515, FPECS-R1010, FPECSP-2020) are the most visible option and suit open car parks, campuses, and public spaces where clear identification from a distance is important. The pole-mount FPECS-PM22 is the most cost-effective option where an existing structure is available. Pillar and pedestal enclosures (FPECP-QR, FPECP-BCC) provide the largest internal equipment space and suit installations requiring multiple devices - intercom, reader, keypad, and power supply - in a single enclosure. The bollard format (FPECP-DB1400) suits pedestrian-level applications at building entries and car park access points, while the wall-mount FPECP-WM is the appropriate choice for covered walkways, building facades, and internal locations.

All FERN360 emergency call point enclosures are available made to order. For project pricing, configuration advice, or to discuss specific site requirements, browse the full FERN360 Emergency Call Point range at Essential Security Supplies NZ. You can also explore our Access Control Reader and Intercom Bollards and Entrance Systems collections for related products. For further reference on public safety communication standards in New Zealand, the New Zealand Security Association (NZSA) provides industry guidance relevant to emergency communication system specification and installation.
