Glass-Break vs Shock and Vibration Detectors: Which Protection Method Works Where?

Start with the attack you need to detect

A shopfront, office window and service door can present very different intrusion risks. An acoustic glass-break detector listens for a glass-breaking event. A shock or vibration detector monitors disturbance in the surface or structure where it is installed. Their purpose overlaps at the perimeter, but the event they measure and the way they are commissioned differ.

The useful question is therefore not which technology is universally best. It is whether the chosen detector can reliably recognise the relevant attack at the actual opening, while remaining stable during normal building activity. For New Zealand commercial projects, include glazing construction, frames, signage, curtains, traffic and operating hours in that assessment.

Use perimeter detection as part of the overall alarm design. It may complement opening contacts and internal motion detection. No single detector should be described as detecting every possible entry method, and product selection does not by itself establish a compliant installation.

Acoustic glass-break detection needs a suitable sound path

An acoustic detector analyses sound associated with breaking glass. Manufacturers may use multiple frequency bands, timing analysis or other processing. Follow the exact model's guidance for supported glass types, pane sizes, mounting positions and effective range. An advertised radius is not evidence that every window within that distance is protected.

Rooms affect sound. Partitions, heavy curtains, deep reveals, furnishings and enclosed display areas can change the path between the pane and detector. Assess the room in its final trading or occupied layout, including blinds in the position used when the system is armed.

RISCO's glass-break detector documentation provides model information and installation references. The Vitron Plus RG71FM0G3000B is a wired product example in the Essential Security Supplies catalogue. Verify its exact instructions rather than transferring installation rules from another Vitron version.

Shock detection depends on the protected structure

A shock detector responds to vibration transmitted through its mounting surface. The result depends on the structure as well as the sensor. A solid timber frame, flexible aluminium section and masonry wall do not transmit an impact in the same way. Fixing position, substrate joints and mounting security can therefore be decisive.

The RISCO ShockTec documentation describes vibration analysis and a combined magnetic-contact option. In the catalogue, the ShockTec Plus RK601SMG300A with magnet illustrates how impact detection and opening detection can be combined in a device. Confirm how those functions are wired and identified at the panel.

Do not assume that a general shock detector is a certified seismic detector for safes or vaults. High-security applications can involve different attack signatures, mounting requirements and approvals. Obtain the exact application documentation before specifying protection for a safe, strongroom or ATM.

Compare the methods opening by opening

For a retail frontage, an acoustic detector may offer a useful way to cover several compatible panes from an approved position. However, film, laminated construction or changes to the display layout need specific checking. Do not promise performance on treated or unusual glazing without manufacturer confirmation.

For a service door or vulnerable frame, a suitable shock detector may help identify an attack involving impact or forced movement. It must still be calibrated on the installed structure. A sensor adjusted on a test board has not been commissioned for the actual door.

Sometimes the appropriate answer is layered protection. A magnetic contact can report opening, a perimeter detector can address a defined attack event, and internal detection can cover subsequent movement. Describe each layer's purpose so the customer understands both coverage and limitations.

Calibrate without creating a nuisance alarm problem

Sensitivity is a commissioning decision, not a setting to maximise. Excessive sensitivity can turn normal door closure, nearby work or building vibration into unwanted events. Insufficient sensitivity can miss the intended disturbance. Use the manufacturer's approved method to establish the setting and record the result.

For acoustic detectors, use the specified glass-break simulator and the test sequence required for that detector. A hand clap, phone recording or arbitrary impact is not a substitute for an approved test. Check each protected pane from the relevant position and include curtains or blinds as required by the instructions.

For shock detectors, follow the approved impact test without damaging the building. Test normal activities as well as the intended attack simulation. Do not strike glazing or structural elements in an uncontrolled way. Agree access and test arrangements with the site operator before commissioning.

The RISCO RWT62W43300A wireless shock detector with contact is another catalogue example. Wireless versions also require receiver compatibility, frequency, supervision and battery checks. A shared brand name does not establish that every wireless detector works with every receiver or firmware version.

Configure zones for a useful response

Choose zone descriptions that identify the actual opening or protected area. A report labelled only 'perimeter' may slow investigation when several shopfront sections exist. Where separate outputs or separately enrolled functions are supported, plan how impact, opening and tamper events will be distinguished.

Discuss the armed state with the customer. A perimeter zone may be active while people remain inside, so ordinary activity near the window or door matters. Do not make a zone permanently active without confirming the operational requirement and the panel's programming options.

Check supply voltage at wired devices and the total standby load. Confirm tamper operation, end-of-line supervision and the event received at the monitoring centre. For wireless equipment, test in the final enclosure and mounting location, then record signal and supervision results using the manufacturer's method.

Keep commissioning records with the maintenance plan. Reassess after glazing replacement, security-film installation, shop refits, new curtains or nearby machinery changes. Browse the commercial alarm equipment range when coordinating the perimeter devices with the panel and the rest of the system.

Frequently asked questions

Can one glass-break detector protect an entire shopfront?

Possibly, within its documented application limits. Check every pane, the glass construction, distances, mounting position and acoustic obstructions using the approved test procedure. Room size alone is insufficient.

Will shock detection report a window being opened normally?

Not necessarily. Opening detection requires an appropriate contact function or separate magnetic contact. Check the exact product and zone configuration rather than assuming vibration detection covers opening.

Can I use an ordinary sound recording to test glass-break protection?

Use the manufacturer's specified simulator and procedure. A recording may not reproduce the required frequencies, timing or test conditions and cannot establish that the installed protection is satisfactory.

Is a shock detector suitable for every safe or vault?

No. Those applications may need a dedicated seismic detector and specific installation evidence. Confirm the protected construction, threat and required approvals before selecting a device.
