Understanding Modern Alarm System Architecture in NZ
Choosing between a wired and wireless alarm system is one of the most fundamental decisions in any security installation. Both technologies have matured significantly, and today's professional-grade systems from brands like Risco, EliteControl, and U-Prox deliver reliable, EN 50131-certified protection across both formats. This guide breaks down the key differences, technical trade-offs, and ideal use cases to help installers and procurement teams make the right call for each site.
What Is a Wired Alarm System?
A wired alarm system connects all detection devices, keypads, and sirens to a central control panel via physical cable runs - typically 4-core or 6-core security cable. The control panel provides power to the devices along the same cabling, which eliminates the need for batteries at individual sensor points.
Advantages of Wired Systems
- No battery dependency at sensor level - detectors draw power from the panel, reducing ongoing maintenance.
- Tamper-evident cabling - end-of-line (EOL) resistors detect open circuits, short circuits, and cable cuts.
- High zone capacity - suitable for large commercial and industrial sites with hundreds of detection points.
- Consistent signal integrity - no RF interference risk; ideal for environments with high radio-frequency noise (factories, hospitals, data centres).
- Lower long-term cost - no sensor battery replacements; panel and detector life cycles align.
Limitations of Wired Systems
- Higher installation labour cost - cable runs require concealment, conduit, or surface trunking.
- Disruptive retrofits - difficult to add zones to finished buildings without significant remediation work.
- Fixed sensor placement - relocating a detector requires re-running cable.
What Is a Wireless Alarm System?
Wireless alarm systems communicate between detectors, keypads, and the central panel via ISM-band radio frequency (typically 868 MHz in Europe and ANZ-region products, or 916.5-917 MHz for AU-market devices). Each detector operates on its own battery, and two-way encrypted communication confirms message delivery between the device and the panel.
Advantages of Wireless Systems
- Minimal installation disruption - ideal for heritage buildings, tenanted spaces, and retrofit projects.
- Flexible sensor placement - devices can be repositioned without any cabling work.
- Faster installation time - reduces on-site labour hours significantly for standard residential and light commercial sites.
- Two-way communication - modern wireless protocols (such as U-Prox) provide bi-directional RF, so the panel confirms every transmission and can push OTA firmware updates to field devices.
- Scalable and modular - add detection points without structural work.
Limitations of Wireless Systems
- Periodic battery replacement required at each sensor (typically every 3-5 years with modern lithium cells).
- RF range can be affected by dense masonry, metal structures, or competing 868 MHz devices.
- Higher per-device cost compared to equivalent wired detectors.
Hybrid Systems: The Best of Both Worlds
Modern professional control panels are not limited to a single topology. Hybrid panels - such as the Risco LightSYS+ range - support a combination of wired bus zones and wireless zones on the same panel. This gives installers the flexibility to run hardwired detection in new-build or structured cabling environments, while adding wireless devices in areas where cabling is impractical.
Risco LightSYS and LightSYS+ - Professional Hybrid Alarm Panels
The Risco LightSYS series is a benchmark in professional hybrid alarm architecture. The entry-level LightSYS2 supports 8-50 zones with up to 50 wireless zones, 4 partitions, and integration with the RISCO Cloud for remote access, live video verification, and smartphone app control. The panel supports Grade 2 EN 50131 certification, making it suitable for residential and light commercial applications.
Stepping up, the Risco LightSYS+ scales to 512 zones with 256 dedicated wireless zones, 32+4 partition groups, 2 fast bus lines supporting 32 devices each, and up to 256 two-way keyfobs. It achieves Grade 2 or Grade 3 EN 50131 certification and supports integration with access control, VUpoint IP camera video verification, and the RisControl smart touchscreen keypad. Built-in IP and Wi-Fi (802.11 b/g/n 2.4 GHz) with optional 2G/4G plug-in modules means remote connectivity is built into the architecture.
View our product range for Risco alarm systems.
Product Specifications: Risco LightSYS+ (LPAK-Kit)
| Specification | Detail |
|---|---|
| Panel zones | 8 zones standard, expandable to 512 |
| Wireless zones | 256 |
| Partitions / groups | 32 partitions + 4 groups per partition |
| Bus lines | 2 fast bus lines + 1 auxiliary (32 devices each) |
| Keypads | 32 wired / 32 wireless |
| Keyfobs | 256 (1-way or 2-way) |
| Proximity readers | 48 |
| Wireless sirens | 32 |
| Wired sirens | 24 |
| Programmable outputs | 4-196 |
| User codes | 500 |
| Event log | 2,000 events |
| Connectivity | Built-in IP, Wi-Fi 802.11 b/g/n 2.4 GHz; plug-in 2G/4G |
| Certification | EN 50131 Grade 2 or Grade 3 |
| Housing | Small/large polycarbonate or metal |
| Kit contents | LightSYS+ panel, LCD keypad, 2x DigiSense PET PIR, internal piezo sounder, external siren (blue lens), 12VDC 7Ah battery |
View our product for full LightSYS+ kit configurations and keypad options.
EliteControl: NZ-Focused Wired Alarm Systems with Smart App Integration
EliteControl is a New Zealand-developed alarm system brand offering professional-grade wired control panels combined with the EliteControl smartphone app - delivering smart remote management with no ongoing subscription charges. The EC panel range is designed for residential and light commercial installations where a traditional wired architecture is preferred, but modern app-based monitoring and control is still required.
What the EliteControl App Delivers
When fitted with an IP-MODULE or the EC-i 4G cellular board, EliteControl panels connect directly to the EliteCloud platform. From the smartphone app, users can arm, stay-arm, or disarm the system, review event history, view live sensor status, and operate connected outputs such as garage doors and gates - all from a single interface. Multiple sites can be managed from one app, and multiple users can be assigned to one site, with push notifications for all alarm events including intruder activation, mains power failure/restore, battery failure/restore, panic, fire, medical, and tamper alarms. Notifications can operate standalone or in conjunction with a monitoring station for guard response.
EliteControl EC Alarm Kit Range
The EC kit range provides complete, ready-to-install wired alarm bundles. Each kit includes the EC security and control panel, keypad, two OPT-FLX-S-ST sensors, a 12V 7.5Ah SLA battery, internal and external sounders, and a polycarbonate enclosure with 16VAC 1.4A supply. Keypad options span three formats to suit different installation aesthetics:
- EC-KIT LCD - includes the EC-LCD full English keypad (vertical style) and 100m of 4-core 0.2mm tinned copper cable. Available with blue or black external siren.
- EC-KIT KP W - includes the EC-KP slimline touch interface keypad in white. Available with black external siren variant.
- EC-KIT TOUCH W - includes the EC-TOUCH W 5-inch colour touch screen keypad and 100m of cable. Available with black external siren variant.
4G Cellular and Cloud Connectivity
For sites without reliable fixed-line connectivity, the EC-i 4G cellular board plugs directly onto the EC-i panel's Expansion Port A, adding 4G cellular communication for EliteCloud app connectivity, cloud dashboard access, and third-party monitoring station reporting - without replacing the underlying wired panel architecture.
View our product range for EliteControl alarm kits.
Product Specifications: EliteControl EC Alarm Kits
| Specification | Detail |
|---|---|
| System type | Wired security and control panel |
| Kit keypad options | EC-LCD (full English, vertical), EC-KP (slimline touch), EC-TOUCH (5" colour touchscreen) |
| Included sensors | 2x OPT-FLX-S-ST |
| Battery backup | DM12-7.5 SLA (12V 7.5Ah) |
| Sounders | PS209-R internal piezo + EC-SIREN external (blue or black) |
| Enclosure | EC-PLAS CAB polycarbonate, 16VAC 1.4A supply |
| Cabling (select kits) | 100m 4-core 0.2mm tinned copper |
| Connectivity option | IP-MODULE (IoT/EliteCloud) or EC-i 4G cellular board |
| 4G board expansion port | Expansion Port A (EC-i and EC-PCB compatible) |
| App platform | EliteCloud (iOS/Android); no ongoing subscription |
| Monitoring | Self-monitor via push notification or 3rd party monitoring station |
| OTA updates | Yes (IoT-MODULE and EC-i 4G) |
View our product for the full EliteControl panel and accessory range.
U-Prox: Purpose-Built Wireless Alarm Technology
Where Risco's strength is in scalable hybrid architecture, U-Prox is engineered exclusively for wireless deployments. The U-Prox ecosystem uses ISM-band two-way communication with 256-bit encryption, OTA firmware updates, and a growing library of wireless devices - all manageable via the U-Prox Installer mobile app (iOS/Android). This makes U-Prox a strong choice for installers who want a clean, cable-free installation with professional-grade security credentials.
U-Prox Wireless Detection Devices
The U-Prox wireless sensor range covers the full spectrum of interior and exterior detection needs:
- U-Prox PIR Combi - dual-technology wireless detector combining passive infrared motion detection (12 m, 88° FOV, pet immune to 20 kg) with a glass-breakage microphone (8 m, 120° detection angle). Suitable for living areas, retail spaces, and offices with glazed perimeters. CR123A battery, up to 5 years service life, ENV class II.
- U-Prox PIR Outdoor - IP55-rated outdoor motion detector with advanced anti-masking (detection of full and partial lens blocking, immunity to objects up to 80 cm high). Working distance 3-15 m, 90° detection angle, pet immune to 20 kg, dual CR123A batteries, operating temp -20°C to +55°C, ENV class III. Suited to external building perimeters and car parks.
- U-Prox PIR - indoor wireless motion detector, 12 m, 88° FOV, pet immune to 20 kg, CR123A battery up to 5 years, remote sensitivity adjustment via app. Available in white and black.
U-Prox Perimeter and Access Control Devices
- U-Prox Wireless Door Contact (WDC) - IP55-rated magnetic door/window sensor with capsule construction, reed switch rated to over 1 million operations, external sensor connector, customisable LED/bypass output, and built-in temperature sensor. CR123A battery, up to 5 years, dimensions 85x20.9x20.4 mm, available in white, dark brown, and black. Ideal for door and window perimeter zones.
- U-Prox Keypad G1 - wireless touch mini keypad for one security group. Slim profile (84.5x84.5x14.6 mm), patented fastening system, duress code (last digit +1), backlit, buzzer on entry/exit delay. Two AAA lithium batteries, up to 2 years. RF range up to 4,800 m open air. Available in white and black.
- U-Prox Button - compact programmable panic/alarm button, CR2032 battery up to 5 years, RF range up to 300 m, dimensions Ø39x9x57 mm. Suitable for duress, medical alert, or custom arming triggers.
Product Specifications: U-Prox Core Wireless Devices
| Specification | U-Prox PIR (Indoor) | U-Prox PIR Outdoor V2 | U-Prox WDC Door Contact |
|---|---|---|---|
| Detection range | 12 m | 3-15 m | Reed switch (7-15 mm gap) |
| Detection angle | 88° | 90° | N/A |
| Pet immunity | Up to 20 kg | Up to 20 kg | N/A |
| IP rating | Indoor (ENV class II) | IP55 (ENV class III) | IP55 (ENV class III) |
| Battery | CR123A (up to 5 years) | 2x CR123A (up to 5 years) | CR123A (up to 5 years) |
| RF frequency | 868.0-868.6 MHz / 916.5-917 MHz | 868.0-868.6 MHz / 916.5-917 MHz | 868.0-868.6 MHz / 916.5-917 MHz |
| Communication | Two-way, 256-bit encrypted | Two-way, 256-bit encrypted | Two-way, 256-bit encrypted |
| Operating temp | -10°C to +55°C | -20°C to +55°C | -20°C to +50°C |
| OTA updates | Yes | Yes | Yes |
| Dimensions | 90x60x34.35 mm | 183.8x77.2x88.6 mm (with hood) | 85x20.9x20.4 mm |
View our product range for U-Prox wireless alarm devices.
Wired vs Wireless: Side-by-Side Comparison
| Factor | Wired | Wireless |
|---|---|---|
| Installation disruption | High (cable runs required) | Low (surface-mount only) |
| Retrofit suitability | Difficult in finished buildings | Excellent |
| Ongoing maintenance | Low (no sensor batteries) | Moderate (battery replacement every 3-5 years) |
| Zone capacity | Very high (hundreds of zones) | High (typically up to 256 wireless zones) |
| RF interference risk | None | Low with modern 868 MHz two-way protocols |
| Scalability | Requires cabling for each new zone | Add devices without structural work |
| EN 50131 compliance | Grade 2-3 achievable | Grade 2-3 achievable (with certified devices) |
| Best for | New builds, large commercial sites, high RF environments | Retrofits, heritage buildings, SME, residential |
Which System Should You Specify?
For new-build commercial and multi-tenancy projects where cabling can be installed during construction, a wired or hybrid panel such as the Risco LightSYS+ or an EliteControl EC kit provides the most cost-effective long-term outcome - no battery management overhead, maximum zone capacity, and Grade 3 EN 50131 compliance for high-risk environments.
For retrofit, residential, and SME deployments where minimising disruption is a priority, a dedicated wireless platform such as U-Prox delivers professional-grade security with clean, cable-free aesthetics. Two-way 256-bit RF communication, OTA device management, and IP55-rated outdoor sensors mean wireless is no longer a compromise - it is a professional-grade choice in its own right.
For sites that span both requirements - a new-build core with tenant fitout additions, or a commercial premise with a heritage exterior - the hybrid architecture of the Risco LightSYS range provides the flexibility to mix wired bus zones with wireless devices on a single panel.
For the full range of professional alarm systems and detection devices available in New Zealand, visit our Burglar Alarm Systems collection.
For standards guidance on alarm system grading and installation requirements, refer to the New Zealand Security Association (NZSA) and the applicable Standards New Zealand AS/NZS reference publications for security alarm system design and installation.
