| Wireless Monitor |
Power source |
Main body: Rechargeable battery AAA (R03)
Ni-MH battery (1.2 V, 550 mAh)x2 |
| Dimensions (H x W x D) |
Approx. 173 x 52 x 30 mm (excluding protruding sections) |
| Mass (weight) |
Approx.160 g (including the batteries) |
| Operating environment |
Ambient temperature: Approx. 0 to +40C, Relative humidity (non-condensing): up to 90 % |
| Display size |
2.2-inch colour / QVGA (320 x 240 pixels) |
| Frequency range |
1.88 GHz to 1.90 GHz |
| RF transmission power |
Approx. 10 mW (average power per channel)
250 mW (max.) |
| Operating time |
Standby use: approx. 80 hours*When used fully charged in an operating temperature of 20C. |
| Charging time |
Approx. 8 hours*When the operating temperature is 20C. The charging time may increase when the operating temperature is lower than this. |
| Transmitting range |
Approx. 100 m (line-of-sight distance between the main and wireless monitor) |
| External material |
ABS resin |
| Charger |
Power source |
AC adaptor (5.5 V DC, 0.5 A) |
| Power consumption |
Standby: 0.6 W * , Charing: 1.6 W*When the sub monitor with full-charged batteries is placed on the charger. |
| Dimensions (H x W x D) |
Approx. 43 x 81 x 76 mm (excluding protruding sections) |
| Mass (weight) |
Approx. 70 g (excluding the AC adaptor) |
| Operating environment |
Ambient temperature: Approx. 0 to +40C, Relative humidity (non-condensing): up to 90 % |
| External material |
ABS resin |
