Camera
|
|
Image Sensor
|
1/2.7" CMOS
|
|
Max. Resolution
|
3840 (H) × 2160 (V)
|
|
ROM
|
256 MB
|
|
RAM
|
2 G
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
0.004 lux@F1.0 (Color, 30 IRE)
0.0004 lux@F1.0 (B/W, 30 IRE)
0 lux (illuminator on)
|
|
S/N Ratio
|
>56 dB
|
|
Illumination Distance
|
Up to 30 m (98.43 ft) (IR)
Up to 30 m (98.43 ft) (Warm light)
|
|
Illuminator On/Off Control
|
Auto;Manual
|
|
Illuminator Number
|
1 (IR LED); 1 (Warm light)
|
|
Angle Adjustment
|
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M12
|
|
Focal Length
|
2.8 mm; 3.6 mm
|
|
Max. Aperture
|
F1.0
|
|
Field of View
|
2.8 mm: H: 106°; V: 55°; D: 125°
3.6 mm: H: 85; V: 45°; D: 102°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 1.5 m (4.92 ft)
3.6 mm: 2.2 m (7.22 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
66.0 m
(216.54 ft)
|
26.4 m
(86.61 ft)
|
13.2 m
(43.31 ft)
|
6.6 m
(21.65 ft)
|
|
3.6 mm
|
78.0 m
(255.91 ft)
|
22.2 m
(102.36 ft)
|
15.6 m
(51.18 ft)
|
7.8 m
(25.59 ft)
|
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
|
Intelligence
|
|
IVS (Perimeter Protection)
|
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human), stay detection, loitering detection
|
|
Face Detection (Full Image)
|
Face detection; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting.
|
|
SMD
|
SMD 4.0
|
|
AcuPick
|
Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets.
|
|
AI SSA
|
Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions.
|
|
Smart Search
|
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
|
|
Video
|
|
Video Compression
|
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
|
|
AI Coding
|
AI H.265; AI H.264
*Includes smart codec technology, Smart H.265+ and Smart H.264+
|
|
Video Frame Rate
|
Main stream: 3840 × 2160 @(1 fps–25/30 fps)
Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
Third stream: 1920 × 1080@(1–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Stream Capability
|
3 streams
|
|
Resolution
|
8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520/2560 × 1440); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
|
|
Bit Rate Control
|
CBR/VBR/ABR
|
|
Video Bit Rate
|
H.264: 3 kbps–16384 kbps;
H.265: 3 kbps–16384 kbps
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120 dB
|
|
Scene Self-adaptation (SSA)
|
Yes
|
|
White Balance
|
Auto; natural; street lamp; outdoor; manual; regional custom
|
|
Gain Control
|
Auto
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Smart Illumination
|
Yes
|
|
Defog
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
LDC
|
Yes
|
|
Audio
|
|
Built-in MIC
|
Yes
|
|
Built-in Speaker
|
Yes
|
|
Audio Compression
|
PCM; G.711a; G.711Mu; G.726; G.723
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; stay detection; loitering detection; face detection (full image); scene changing; audio detection; voltage detection; external alarm; SMD; security exception
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Network Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; P2P
|
|
Interoperability
|
ONVIF (Profile S; Profile G;Profile T); CGI
|
|
User/Host
|
20 (Total bandwidth: 64 M)
|
|
Storage
|
FTP;SFTP; Micro SD card (support max. 512 GB); NAS
|
|
Browser
|
IE: IE 9/11
Chrome
Firefox
|
|
Management Software
|
SmartPSS Lite; DSS; DMSS
|
|
Mobile Client
|
iOS;Android
|
|
Security
|
Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog; HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade
|
|
Certification
|
|
Certifications
|
CE-LVD: EN 62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
|
|
Port
|
|
Audio Input
|
1 channel (RCA port)
|
|
Audio Output
|
1 channel (RCA port)
|
|
Alarm Input
|
1 channel in: wet contact, 5 mA 3–5 VDC
|
|
Alarm Output
|
1 channel out: wet contact, 300 mA 12 VDC
|
|
Power
|
|
Power Supply
|
12 VDC; PoE
|
|
Power Consumption
|
Basic: 4.5 W (12 VDC); 5.8 W (PoE)
Max. (H.265+WDR+ warm light+siren and light active deterrence + intelligence on): 8.6 W (12 VDC); 10.1 W (PoE)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Operating Humidity
|
≤95%
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing Material
|
Metal
|
|
Product Dimensions
|
Φ122.0 mm × 110.9 mm (4.80" × Φ4.37")
|
|
Net Weight
|
0.75 kg (1.65 lb)
|
|
Gross Weight
|
0.92 kg (2.03 lb)
|
