• Support IEEE802.3 at standard, compatible with IEEE802.3 af by electrical equipment (PD)
• Supports PoE Power up to 30W for each PoE port;
• Auto detect power device; will not burned non-standard PoE device or normal PoE switch;
• Supports port power supply prioritization, guarantee the continuous power supply of key nodes;
• Supports IEEE802.3 x full duplex flow control and Backpressure half duplex flow control;
• Line-speed forwarding, intelligent identification
• Supports storage – and- forward for Data exchange;
Specifications:
| Hardware Specification | ||||||||
| Ports Type | 16×1000Mbps PoE ports (RJ45)+2×1000Mbps ports(RJ45)+2×1000Mbps ports（SFP） | |||||||
| Standards | IEEE802.3, IEEE802.3u, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at | |||||||
| Switching capacity | 40 Gbps | |||||||
| MAC | 8K | |||||||
| Packet Buffer | 4 M bit | |||||||
| Forwarding performance | 29.76Mpps | |||||||
| PoE | support POE | |||||||
| Cooling Fans | 1 | |||||||
| Weight | <4.2 kg | |||||||
| Operating humidity | 10%～90% (non-condensing) | |||||||
| Dimensions (W×D×H) | 280mm x 180mm x 44mm (11"×7.1"×1.7") |
|||||||
| Working Mode | Default (Normal mode) : All ports can communicate with each other, VLAN (Secure mode): Downlink ports can communicate only with uplink ports., Extend (Surveillance mode): Transmission distance up to 250 meters. Downlink ports can communicate only with uplink ports | |||||||
