Door Loops and Power Transfer Devices: Safe Door Wiring NZ

An access-controlled door is a moving mechanical assembly, not simply a fixed electrical load. Power and monitoring cables often have to pass between a stationary frame and a moving leaf. The wrong transfer method can pinch conductors, fatigue strands, damage a rated door or interrupt the supply to an electric lock. For New Zealand installers, selecting a door loop or concealed power transfer is therefore a mechanical, electrical and life-safety design task. This guide concentrates on choosing, routing and commissioning the transfer path rather than providing a general introduction to access control.

Understand what crosses the door-to-frame boundary

List every conductor before selecting a transfer fitting. An electric lock may need a positive supply and return, while a monitored lock can require additional status circuits. Depending on the device, the door may also carry a reader, request-to-exit button, tamper input or separate door position sensor. Do not assume that a two-core cable is adequate merely because the lock operates from two terminals. Start with the manufacturer's wiring diagram, note conductor count, shielding and conductor size, then allow for a sensible service margin without filling the fitting beyond its specified capacity.

Decide whether the wiring must be flexible across the hinge line or can pass through a purpose-built concealed assembly. An exposed loop is visible and comparatively accessible; concealed transfer hardware can provide a neater result but requires suitable door and frame preparation. The transfer device is a pathway, not a substitute for proper cable protection or strain relief. Consider the door opening angle, leaf thickness, frame construction, hinge position, accessible working space and whether the installation is exposed to weather or deliberate interference.

Compare exposed loops and concealed power transfers

An exposed flexible door loop typically forms a protected arc between frame and leaf. Its location and length must allow the full movement of the door without becoming taut, snagging hardware or contacting a sharp edge. Concealed transfer units route wiring through a protected hinge-side mechanism and can be appropriate where appearance or tamper resistance matters. Both options have limitations: exposed loops can be damaged by carts or occupants, while concealed hardware may be incompatible with certain profiles, pivots or fire-rated assemblies.

Do not confuse a surface loop with an electrical slip ring or a specialised continuous hinge solution. Each mechanism is designed for different movement and cable geometry. A narrow aluminium-stile door, a heavy commercial timber leaf and a steel security door can demand different fittings even where the same access controller is installed. Review the transfer manufacturer's approved door construction and installation template before drilling. Never cut a fire-rated leaf or frame without documented approval for the particular assembly.

Size conductors and account for voltage drop

A lock that receives adequate voltage with the door stationary may fail intermittently when current rises during operation or when a damaged cable flexes. Determine the manufacturer's acceptable voltage range and peak or operating current. Calculate the complete outgoing-and-return circuit length, including travel through the transfer fitting. Where the lock has a high inrush current, base conductor selection and power supply margin on the relevant worst-case load rather than a low standby figure.

Keep power and signal functions identifiable. If the manufacturer requires screened cable, observe the stated termination approach rather than bonding the screen at arbitrary points. Maintain appropriate separation from mains wiring and use equipment and installers suitable for the electrical work involved. Document the supply voltage measured at the lock under real operating conditions. A continuity test alone does not prove that a long, undersized cable can support reliable operation.

Plan mounting position and mechanical protection

Place the transfer near the hinge side or the manufacturer's specified zone where movement is predictable. Confirm the minimum bend radius and required slack at fully open, partly open and closed positions. Avoid trapping cable behind a closer arm or placing an exposed loop where pallet trucks and furniture regularly pass. Fit approved grommets or bushings at penetrations, remove burrs and provide strain relief so force is not carried by electrical terminations.

Outdoor and wash-down environments add moisture and corrosion concerns. Choose fittings and cable sheath suitable for those conditions, and design any water path so liquid cannot run directly into an electrical enclosure. On security doors, consider whether an accessible external loop increases tampering risk. Where appearance matters, concealed hardware may be attractive, but it should never override manufacturer clearances, fire-door approval or emergency egress requirements.

Keep the locking system safe during faults

Decide what the lock must do on loss of power using the door's approved egress design and the lock manufacturer's instructions. Fail safe and fail secure describe different power-loss behaviour and neither term alone establishes legal compliance. Fire-alarm interfaces, manual release arrangements, accessibility and building consent requirements may apply depending on use. The transfer fitting must not defeat those features when its cable fails or shorts.

If a monitored strike or bolt is installed, identify the exact meaning of each status output. A door contact indicates leaf position; a lock sensor may indicate mechanism state, and an armature bond sensor can indicate magnetic holding contact. These are not interchangeable indications. Commission the access controller's normal, alarm, fault and power-loss states with the actual hardware. Any safety-critical design decision should be reviewed by the responsible door hardware, fire and building professionals.

Commission with movement and repeatable records

Inspect the finished pathway with the door operated through its full designed travel repeatedly. Check for rubbing, overstretch, fastener movement and changes in measured voltage as the leaf moves. Operate the lock under load and verify status inputs at both the local controller and the monitoring software. Test with the closer fitted and correctly adjusted, not only with the door loose on its hinges.

Record the installed transfer model, cable type, core allocation, circuit voltage, lock current, routing photos and any door assembly approvals. Explain maintenance inspection points to the facility manager. High-use doors deserve periodic checks for jacket wear and loose fittings. Repeated intermittent faults often reveal a wiring or movement problem rather than a defective access controller.

Door loop versus concealed power transfer: practical selection table

This table is a selection aid, not a substitute for a current product datasheet or door-assembly approval. A device described as suitable for an access-controlled door is not automatically approved for every fire-rated or smoke-control door.

Worked voltage-drop example for a 12 V electric lock

For a simple two-core DC circuit, a first-pass estimate is voltage drop = current × total conductor resistance. For example, if an illustrative lock draws 0.5 A and the measured or calculated resistance of the complete supply-and-return wiring is 1.2 ohms, the drop is 0.6 V. With 12.0 V at the power supply terminals under load, approximately 11.4 V would reach the lock before allowing for connectors or other losses. Whether that is acceptable depends entirely on the device's stated voltage limits.

Measure the actual lock terminal voltage during the relevant operating state and repeat the measurement as the door moves. The example is not a cable-size recommendation: route length, conductor material and cross-section, operating temperature, joints, lock inrush and regulated supply behaviour all affect the result. Where a monitored lock has multiple circuits, document the power and signal conductors separately.

Troubleshooting intermittent faults at the hinge side

If a lock drops out only when a door opens, start with a visual check for an over-tight loop, compressed jacket, exposed conductor or strain at its terminals. Isolate the relevant circuit before intrusive inspection and follow site safety procedures. Compare voltage at the supply and lock while the circuit is operating; a voltage difference that changes with door position can indicate a damaged conductor, poor joint or excessive resistance.

If lock power remains stable but the controller reports unexplained forced-door or lock-status events, check each monitored contact independently against its wiring diagram. Do not bypass egress releases, fire-alarm inputs or protective circuits to make a fault disappear. Record the fault condition, remedy and completed retest for the handover documentation.

Specification checklist for NZ projects

Confirm the door type and rating; opening angle and hinge geometry; number and size of conductors; lock operating and peak load; acceptable voltage at the door; environmental exposure; mechanical damage risk; compatibility with closers and seals; and inspection access. These details are more useful than selecting by price or appearance alone.

For related hardware, review the genuine IT403A door loop and IT403B door loop listings, then compare requirements with a monitored strike. Product page titles alone do not confirm conductor capacity or fire-door approval; obtain the applicable current datasheet and installation instructions before finalising the specification.

Frequently asked questions

Can I use ordinary alarm cable through a door loop?

Only when the transfer device and cable manufacturer permit it, and when the cable is suitable for the expected repeated flexing, conductor count, voltage drop and environmental conditions. Fixed installation cable can be unsuitable for continuous movement.

Can I drill a fire-rated door for a concealed transfer?

Do not drill or modify a rated assembly without approval for the specific door, frame and hardware arrangement. Obtain evidence from the door manufacturer or responsible compliance professional.

Does a monitored lock need more cores?

Often it does, but the actual number depends on the lock wiring diagram and which feedback signals the access system requires.

How do I test a completed installation?

Cycle the door through full travel, inspect cable movement, measure loaded voltage and test lock operation plus each monitored status and relevant power-loss or release state.
