Full height rotor turnstiles represent the gold standard in perimeter access control. The FERN360 range delivers that standard with precision engineering, four material finish options, and broad integration capability across leading access control platforms. Whether you are securing a critical infrastructure site, a high-traffic commercial facility, or an industrial zone, the FERN360 full height rotor turnstile is built to perform in New Zealand conditions.

FGES-RTFH600-1 FERN360 Full Height Stainless Steel Rotor Turnstile - single lane 600mm pass-through access control unit

What Is a Full Height Rotor Turnstile?

A full height rotor turnstile — sometimes called a full height rotary turnstile or rotor gate — is a floor-to-ceiling access control barrier that permits only one person to pass per authorised credential. Unlike waist-high or tripod turnstiles, full height rotor turnstiles provide a complete physical barrier, eliminating the risk of tailgating, climbing over, or ducking under.

The FERN360 range uses a 360° rotating rotor mechanism, allowing controlled bi-directional or uni-directional passage depending on configuration. This makes them the preferred choice for environments where absolute access integrity is non-negotiable.

The FERN360 Full Height Rotor Turnstile Range

The FERN360 range spans multiple configurations to suit varying site requirements and throughput demands:

  • Single-lane rotor turnstiles — ideal for controlled entry points with moderate throughput, available in 600mm, 650mm, and 900mm pass-through widths
  • Double-lane rotor turnstiles — for high-traffic facilities requiring parallel access lanes, available in 550mm, 650mm, and 900mm pass-through widths
  • Bi-directional models — supporting both entry and exit through a single unit
  • Uni-directional models — for one-way flow control in secure zones
  • Emergency egress configurations — designed to fail-safe open or fail-secure depending on site safety requirements

Each model is engineered for outdoor and indoor deployment, with IP-rated enclosures and corrosion-resistant finishes suited to New Zealand's coastal and industrial environments.

FGES-RTFH650-2 FERN360 Full Height Stainless Steel Rotor Turnstile - single lane 650mm pass-through SUS304 finish

Technology and Integration

FERN360 full height rotor turnstiles are built around a precision electromechanical rotor mechanism with the following core capabilities:

  • Electromechanical solenoid locking — smooth, reliable locking and release cycles with low maintenance requirements
  • Access control integration — compatible with leading platforms via RS485 and dry contact interfaces
  • Credential agnostic — supports IC cards, ID cards, RFID, barcode scanners, PIN pads, biometric readers, and facial recognition modules
  • Anti-tailgating sensors — infrared or optical detection to prevent unauthorised follow-through
  • Bi-directional traffic management — configurable for entry-only, exit-only, or two-way passage
  • Emergency release — automatic fail-safe or fail-secure modes for fire alarm and power failure scenarios
  • Remote management — compatible with building management systems (BMS) and security management platforms for centralised control and audit logging
  • Tamper detection — built-in alarms triggered by forced rotation or physical attack

Where FERN360 Full Height Rotor Turnstiles Are Used

The FERN360 range is deployed across a wide range of high-security and high-traffic environments throughout New Zealand and internationally:

  • Critical infrastructure — power stations, water treatment facilities, data centres, and telecommunications sites
  • Industrial and manufacturing — factory entrances, warehouses, and restricted production zones
  • Transport hubs — rail stations, bus depots, airports, and port facilities
  • Commercial buildings — corporate headquarters, government offices, and multi-tenant facilities
  • Sports and entertainment venues — stadiums, arenas, and event centres requiring high-throughput ticketed entry
  • Correctional and secure facilities — prisons, detention centres, and court complexes
  • Educational campuses — universities and schools with controlled zone access
  • Retail and logistics — distribution centres and high-value storage facilities
FGES-RTDFH900-2 FERN360 Full Height Stainless Steel Rotor Turnstile - double lane 900mm wide pass-through for high-traffic facilities

Material Options: Choosing the Right Finish for Your Environment

The FERN360 full height rotor turnstile range is available in four primary material finishes, each suited to different environmental and aesthetic requirements.

Galvanised Steel

Hot-dip galvanised steel provides a cost-effective, corrosion-resistant option for outdoor installations in moderate environments. The zinc coating bonds metallurgically to the steel substrate, offering reliable protection against rust and weathering. Galvanised turnstiles are well suited to industrial sites, construction zones, and budget-conscious projects where function takes priority over aesthetics.

FGES-RTFH650-2G FERN360 Full Height Galvanised Steel Rotor Turnstile - hot-dip galvanised finish for outdoor industrial use

Powder Coated Steel

Powder coated steel combines structural strength with a wide range of colour and finish options, making it a popular choice for commercial and public-facing installations. The electrostatically applied coating provides a durable, UV-resistant surface that resists chipping and fading. Powder coated FERN360 turnstiles are ideal for corporate campuses, transport hubs, and venues where brand consistency or architectural integration is important.

SUS304 Stainless Steel

SUS304 is the most widely used grade of austenitic stainless steel, offering excellent corrosion resistance in standard atmospheric and mildly corrosive environments. With approximately 18% chromium and 8% nickel, SUS304 provides a clean, professional Hairline 400 finish with strong mechanical properties. It is well suited to indoor installations, sheltered outdoor environments, and general commercial applications.

SUS316 Stainless Steel — Our Recommended Choice

SUS316 stainless steel is our preferred specification for the FERN360 full height rotor turnstile range — and for good reason.

SUS316 adds molybdenum to the SUS304 alloy composition, significantly enhancing resistance to chloride-induced corrosion, pitting, and crevice corrosion. According to the Specialty Steel Industry of North America (SSINA) grade selection guide, molybdenum-bearing grades such as 316 are specifically recommended for marine and chloride-exposed environments — conditions that are common across New Zealand's coastline. This makes SUS316 the material of choice for:

  • Coastal and marine environments — New Zealand's extensive coastline means many sites are exposed to salt-laden air that rapidly degrades lesser materials
  • Industrial chemical environments — facilities handling chlorine, acids, or other corrosive substances
  • High-humidity and wet areas — car parks, outdoor transit hubs, and waterfront facilities
  • Food processing and pharmaceutical sites — where hygiene standards demand non-reactive, easy-to-clean surfaces
  • Long-term, low-maintenance installations — SUS316 delivers a longer service life with minimal surface degradation, reducing total cost of ownership

For New Zealand conditions specifically, SUS316 is the smart long-term investment. The additional cost over SUS304 is consistently offset by reduced maintenance, longer service intervals, and superior appearance retention over the life of the installation.

FGES-RTDFH900-2S FERN360 Full Height SUS316 Stainless Steel Rotor Turnstile - double lane recommended for coastal and marine environments in New Zealand

FERN360 Full Height Rotor Turnstile — Product Specifications

The following specifications apply across the FERN360 full height rotor turnstile range. Individual model dimensions and weights vary — refer to each product listing for model-specific data.

Specification Detail
Material Galvanised Steel / Powder Coated Steel / SUS304 Stainless Steel / SUS316 Stainless Steel
Finish Hairline 400 (stainless) / Hot-dip galvanised / Powder coated (colour options available)
Pass-through Width 550mm / 600mm / 650mm / 900mm (model dependent)
Lane Configuration Single lane or double lane
Traffic Direction Uni-directional or bi-directional (configurable)
Operating Speed 0.2 seconds per cycle
Throughput 25–35 people per minute
Power Supply AC 100–240V, 50/60Hz
Locking Mechanism Electromechanical solenoid lock with cam and dropper
Interfaces RS485, dry contact
Credential Compatibility IC card, ID card, RFID, barcode, fingerprint / biometric
Operating Temperature -15°C to +60°C
IP Rating IP54 (FGES-RTFH600-1) / IP65 (all other models)
Wall Thickness 1.5mm
Supply Made to order

View our product — full model specifications including dimensions and weights are listed on each individual product page.

Why Choose FERN360 Full Height Rotor Turnstiles?

  • Complete physical barrier — no tailgating, no bypass
  • Four material options to suit any environment or budget
  • SUS316 stainless steel available for maximum corrosion resistance in coastal NZ conditions
  • Compatible with all major access control platforms via RS485 and dry contact
  • Configurable for bi-directional or uni-directional flow
  • Emergency egress compliant — fail-safe or fail-secure modes available
  • IP65 rated across most models for outdoor deployment
  • Made to order — contact us to discuss your site requirements
