FERN360 Surveillance Camera and NVR Kits: Choosing the Right System for Your Site

FERN360 IP surveillance camera and NVR kits are engineered for professional installation across commercial, industrial, and high-security residential sites throughout New Zealand. Each kit pairs Starlight-grade cameras with a matched Network Video Recorder, delivering a complete, PoE-powered system that is ready to deploy from a single box.

---

The Role of IP Surveillance Kits in Modern Security Installations

Standalone cameras are only part of the picture. A matched camera-and-NVR kit ensures that resolution, compression codec, PoE power budget, and channel count are all pre-validated to work together - reducing commissioning time and eliminating compatibility guesswork on site. FERN360 kits use S+265 (Super H.265) compression, which delivers significantly smaller file sizes than standard H.264 without sacrificing image quality, making them well suited to sites where storage capacity and bandwidth are a consideration.

All FERN360 cameras in the range carry an IP67 weatherproof rating, built-in IR illumination to 30m, and Starlight low-light performance down to 0.002 Lux at F1.6 - making them appropriate for both indoor and outdoor deployment in New Zealand's variable climate conditions.

---

Camera Types in the FERN360 Range

FERN360 surveillance kits are available with three camera form factors, each suited to different installation scenarios.

Bullet Cameras - Motorised Varifocal Lens

Bullet cameras are the preferred choice for long-range directional coverage - perimeter fencing, driveways, car parks, and loading docks. The motorised varifocal lens (2.8-12mm) allows the focal length to be adjusted remotely after installation, which is particularly useful when the final camera position is confirmed on site rather than at the design stage. Bullet kits are available in 2-camera and 4-camera configurations paired with 5ch, 10ch, or 20ch NVRs.

Turret Cameras - Fixed and Motorised Lens

Turret cameras offer a low-profile, vandal-resistant form factor that suits internal corridors, reception areas, retail environments, and building entry points. The ball-and-socket mount allows the camera head to be repositioned without removing the base, simplifying angle adjustments during commissioning. Fixed lens (2.8mm) models are available for standard field-of-view applications, while motorised varifocal (2.8-12mm) models suit installations where zoom flexibility is required.

Vandal Dome Cameras - Fixed Lens

Vandal dome cameras are housed in a reinforced dome casing designed to resist tampering and physical impact. They are well suited to public-facing environments including retail stores, hospitality venues, and transport hubs where camera interference is a risk. The fixed 2.8mm lens provides a wide field of view appropriate for monitoring open areas and entry points at close to medium range.

---

NVR Channel Options - Matching Recorder to Site Scale

FERN360 NVRs are available in three channel configurations to match the scale of the installation:

• 5-channel NVR - 4x RJ45 PoE ports, supports up to 5 cameras, 1x SATA bay (up to 10TB), HDMI 4K output. Suited to small commercial sites, single-tenancy retail, or residential installations requiring a compact, cost-effective recorder.
• 10-channel NVR - 8x RJ45 PoE ports, supports up to 10 cameras, 1x SATA bay (up to 10TB), HDMI 4K output. Suited to medium-scale commercial sites, multi-zone retail, or light industrial environments.
• 20-channel NVR - 8x RJ45 PoE ports, supports up to 20 cameras, 1x SATA bay (up to 10TB), HDMI 4K output. Suited to large commercial, industrial, or multi-building sites requiring high camera density with room to expand.

All NVRs in the range include 4 alarm inputs and 1 alarm output, Automatic Network Replenishment (ANR) for local camera-side recording during network interruptions, VCA detection alarm support, smart search and playback, and Web6 plug-in-free browser access. Camera transmission distance is supported up to 200m over PoE.

---

HDD Storage Options

Several kits in the FERN360 range are available with or without a pre-installed hard drive. No-HDD variants allow installers to specify their own storage to match retention requirements - a common preference on commercial projects where the client specifies a minimum recording period. Kits with a 2TB HDD pre-installed are available for straightforward deployments where storage selection is not a project variable. The NVR SATA bay supports drives up to 10TB, providing significant headroom for extended retention at full resolution.

For guidance on calculating storage requirements based on camera count, resolution, and retention period, refer to the New Zealand Security Association (NZSA) technical resources and industry guidelines.

---

Product Specifications

Specification	Detail
Camera Sensor	1/2.8" CMOS - Starlight
Resolution - 5MP Models	5MP (2592x1944) @ 20fps
Resolution - 4MP Models	4MP (2592x1520) @ 25fps
Lens - Motorised Varifocal	2.8-12mm motorised zoom (remote adjustment)
Lens - Fixed	2.8mm fixed
Low-Light Sensitivity	0.002 Lux @ F1.6
WDR	120dB Wide Dynamic Range
IR Illumination	Built-in IR LED, max 30m range
Video Compression	S+265 / H.265 / H.264
Analytics	Tripwire, perimeter intrusion detection, VCA alarm
Local Storage (Camera)	Micro SD up to 512GB
Audio	Built-in microphone
Power	12V DC / PoE (IEEE 802.3af)
Housing - Bullet/Turret 5MP	Metal housing
Housing - Vandal Dome/Fixed Turret 4MP	Metal and plastic housing
IP Rating	IP67 (weatherproof)
NVR Channels	5ch, 10ch, or 20ch (kit dependent)
NVR PoE Ports	4x RJ45 PoE (5ch NVR) / 8x RJ45 PoE (10ch and 20ch NVR)
NVR Max Resolution Input	Up to 8MP
NVR Video Output	1x HDMI (up to 4K 3840x2160) + 1x VGA
NVR Storage	1x SATA bay, up to 10TB
NVR Alarm I/O	4 alarm inputs, 1 alarm output
NVR Camera Transmission	Up to 200m over PoE
NVR Remote Access	Web6 plug-in-free browser, cloud upgrade supported
Kit Configurations	2-camera and 4-camera kits available
HDD Options	No HDD (installer-supplied) or 2TB pre-installed (kit dependent)

View our product range for full model-specific configurations, channel options, and HDD variants.

---

Selecting the Right Kit for Your Installation

The right kit depends on three primary variables: camera form factor, channel count, and storage preference. As a general guide:

• Use bullet cameras for perimeter, driveway, and long-range directional coverage where the motorised lens allows post-installation focal adjustment.
• Use turret cameras for internal zones, entry points, and environments where a low-profile form factor is preferred.
• Use vandal dome cameras for public-facing or high-tamper-risk environments where housing robustness is a priority.
• Select a 5ch NVR for small sites with up to 4 active cameras and limited expansion requirements.
• Select a 10ch or 20ch NVR for medium to large sites, or where future camera expansion is planned.
• Specify a No HDD variant when the project requires a specific drive capacity or brand, or when storage is being procured separately.

---

Installation Accessories

FERN360 also supplies a range of installation accessories to support professional camera deployment, including corner mount adaptors (FGSIP-BKCM-35) for wall-to-corner transitions, junction boxes (FGSIP-BKJB-3) for motorised vandal dome cameras, and dedicated surveillance camera poles for elevated mounting positions. These accessories are designed to complement the camera range and simplify installation on non-standard surfaces.

---

Why Choose FERN360 Surveillance Kits

FERN360 surveillance kits are stocked and supported locally in New Zealand through Essential Security Supplies, providing access to technical support, compatible accessories, and reliable supply for both single-site and multi-site installations. The range covers entry-level 2-camera configurations through to 4-camera, 20-channel systems, giving installers a consistent product family to specify across projects of varying scale.

For the full range of FERN360 IP surveillance camera and NVR kits available in New Zealand, view our product collection.
