The Role of Tripod Turnstiles in Modern Access Control
Controlling pedestrian access in high-traffic environments demands reliable, durable, and intelligent entry solutions. The FERN360 Tripod Turnstile range delivers exactly that, offering fully automatic stainless steel turnstiles engineered for professional security installations across New Zealand. Whether you need a compact body-only unit or a fully integrated stand-mounted system, the FERN360 FGES-TT550 and FGES-TTS550 series provide a solution to match your site requirements.
What Are Tripod Turnstiles?
Tripod turnstiles are three-arm rotating barriers designed to allow one-way or bi-directional pedestrian access control. They are widely used in commercial buildings, stadiums, transport hubs, gyms, and industrial facilities where controlled entry is essential. Unlike full-height turnstiles, tripod turnstiles offer a compact footprint while still providing a meaningful physical deterrent and reliable access logging capability.
The FERN360 range takes this proven format and elevates it with fully automatic electromagnetic drive technology, wide-range power compatibility, and robust SUS304 stainless steel construction, making them well suited to New Zealand's demanding commercial and industrial environments. For guidance on access control standards applicable to New Zealand installations, refer to the New Zealand Security Association (NZSA), which provides best-practice frameworks for physical security barrier integration.
The FERN360 Tripod Turnstile Range Overview
The FERN360 tripod turnstile range is split into two sub-series:
- FGES-TT550 Series (compact body-only units): Three models differentiated by stainless steel gauge, ideal where a pedestal or housing is already in place or will be custom-fabricated.
- FGES-TTS550 Series (stand-mounted units): Three models that include an integrated stainless steel stand/pedestal, providing a complete, self-contained access control solution ready for installation.
All six models share a common core specification: 550mm passage width, 35 persons per minute throughput, 0.2-second unlock time, and wide-range AC power input (100~240V), making them straightforward to integrate into existing electrical infrastructure across New Zealand.
FGES-TT550 Series: Compact Tripod Turnstile Body Units
The FGES-TT550 series comprises three body-only tripod turnstile models, each sharing the same core dimensions and performance characteristics but differentiated by stainless steel gauge thickness. This allows specifiers and installers to select the appropriate grade for their application's durability requirements.
FGES-TT550-1
The entry-level model in the compact series, the FGES-TT550-1 features a 1.0mm SUS304 stainless steel body with dimensions of 480x280x960mm. It is well suited to lower-traffic indoor environments where a cost-effective, reliable access control solution is required.
FGES-TT550-2
The FGES-TT550-2 steps up to a 1.5mm SUS304 stainless steel body (480x280x980mm), offering enhanced rigidity and resistance to physical wear. This model is recommended for medium-to-high traffic environments or installations where greater structural durability is a priority.
FGES-TT550-3
The FGES-TT550-3 features a 1.2mm SUS304 stainless steel body (480x280x980mm), balancing material strength with cost efficiency. A practical choice for a broad range of commercial access control applications.
FGES-TTS550 Series: Stand-Mounted Tripod Turnstile Units
The FGES-TTS550 series provides the same proven turnstile mechanism as the TT550 series but integrates it into a complete stainless steel stand assembly (1200x280x960mm). This makes the TTS550 series a fully self-contained solution, reducing installation complexity and ensuring a consistent, professional aesthetic. The stand-mounted configuration is particularly well suited to open-plan environments such as lobbies, transport terminals, and event venues.
Notably, the FGES-TTS550-2 and FGES-TTS550-3 models carry an IP65 ingress protection rating, making them suitable for semi-exposed or outdoor-covered installations where moisture and dust resistance are required.
FGES-TTS550-1
The FGES-TTS550-1 features a 1.0mm SUS304 stainless steel body on a full integrated stand. An excellent choice for indoor environments where a clean, professional installation is required without the need for a custom pedestal.
FGES-TTS550-2
The FGES-TTS550-2 upgrades to a 1.2mm SUS304 stainless steel body and adds an IP65 ingress protection rating, making it suitable for covered outdoor or semi-exposed environments. Ideal for transport hubs, covered walkways, and facilities with higher environmental exposure.
FGES-TTS550-3
The flagship of the stand-mounted series, the FGES-TTS550-3 features the heaviest 1.5mm SUS304 stainless steel body and retains the IP65 rating. At 126.92kg, it is the most robust unit in the range, designed for high-traffic, high-demand environments where maximum durability and weather resistance are non-negotiable.
Product Specifications
| Specification | Detail |
|---|---|
| Passage Width | ≤550mm |
| Throughput Rate | 35 persons per minute |
| Unlock Time | 0.2 seconds |
| Drive Mechanism | Electromagnetic drive, DC |
| Input Signal | 12V dry contact |
| Power Supply | 100~240V AC |
| Operational Voltage | 24V DC |
| Max Power Consumption | 30W |
| Frequency | 50~60Hz |
| Working Temperature | -25°C to +70°C |
| Material / Finish | SUS304 Stainless Steel — 1.0mm (TT550-1, TTS550-1) / 1.2mm (TT550-3, TTS550-2) / 1.5mm (TT550-2, TTS550-3) |
| Body Dimensions (TT550 series) | 480x280x960mm (TT550-1) / 480x280x980mm (TT550-2 & TT550-3) |
| Body Dimensions (TTS550 series) | 1200x280x960mm (all stand models) |
| IP Rating | IP65 (TTS550-2 and TTS550-3 only) |
| Weight | 53kg (TT550-1) / 56kg (TT550-2 & TT550-3) / 88.51kg (TTS550-1) / 90.18kg (TTS550-2) / 126.92kg (TTS550-3) |
| Supply / Lead Time | Made to Order — contact Essential Security Supplies NZ for lead times |
For full model-specific data and spec sheets, View our product range or download the individual spec sheets from each product page.
Choosing the Right FERN360 Tripod Turnstile for Your Application
Selecting the correct model comes down to three key factors: installation environment, traffic volume, and whether a stand is required.
For indoor, lower-traffic environments such as small office lobbies or gym entrances, the FGES-TT550-1 or FGES-TTS550-1 (1.0mm body) provides a cost-effective, reliable solution. For medium-to-high traffic commercial environments such as corporate headquarters, retail centres, or transport interchanges, the 1.2mm or 1.5mm body variants offer greater structural longevity. Where outdoor or semi-exposed installation is required, the IP65-rated FGES-TTS550-2 or FGES-TTS550-3 are the appropriate choices.
All models accept 12V dry contact input, making them compatible with a wide range of access control readers, including card readers, biometric scanners, and intercom systems commonly deployed in New Zealand commercial and industrial facilities.
Why Choose FERN360 Tripod Turnstiles from Essential Security Supplies NZ?
Essential Security Supplies is New Zealand's trusted wholesale supplier of professional-grade access control and entrance management systems. The FERN360 Tripod Turnstile range is available on a made-to-order basis, ensuring each unit is manufactured to specification and delivered ready for professional installation.
Our team can assist with model selection, integration advice, and technical support for your access control project. View our product range online or contact us directly for a tailored quote.
